Strain Gauge Data Acquisition Systems

The two primary types of strain gauges are foil strain gauges and semiconductor (piezo-resistive) strain gauges. Foil gauges are the most widely used, offering excellent accuracy, stability, and fatigue resistance for industrial applications. Semiconductor gauges provide higher sensitivity but are more temperature-sensitive. SensorData Technologies integrates strain gauge technology into multi-axis transducers designed for harsh industrial environments.

SensorData Technologies' Turnkey Measurement System transmits data wirelessly at 915 MHz with a range of up to 750 feet. This eliminates the need for cabling on rotating or moving components such as belt conveyors, enabling real-time monitoring from a remotely located base station connected to a PC via USB.

The system supports 4-component simultaneous measurement, capturing tensile force (Fz), horizontal bending moment (Mx), vertical bending moment (My), and twisting moment (Mz). This multi-axis capability enables comprehensive stress analysis and combined stress calculations compared against predetermined maximum allowable values for conveyor and material handling components.

No license is required. The system operates in the ISM (Industrial, Scientific, and Medical) frequency band at 915 MHz, which is license-free. This simplifies deployment in manufacturing facilities and industrial environments, reducing regulatory burden and installation time for engineers and maintenance teams.

The system includes purpose-built data acquisition and display software with archiving capabilities. This software interfaces with the remote base station transceiver via USB and allows real-time visualization of all four measurement axes, historical data archiving, and comparison against benchmark values established for newly installed or repaired conveyor systems.

Yes. SensorData Technologies provides free in-house calibration when the sensor is supplied as part of a complete turnkey system. The company also offers engineering consultation for custom applications, installation guidance, and ongoing technical support from a team of experienced engineers and technicians throughout the product lifecycle.
